This is my Summer Training Report in B.H.E.L., Haridwar on General Awareness Of Steam Turbine in Turbine Block-III in the period 17/06/13 to 31/07/13. I would like to thank My Mentor Mr. Alok Shukla Sir, My Guide Asst. Anuj Dixit Sir.

TRANSCRIPT

• 1.Vocational Training Report Turbine Blade Shop-Block 3 Bharat Heavy Electricals Limited Ranipur,Haridwar (Uttrakhand) Submitted By: Submitted To: Yuganter Rawat Mr.Hitendra Bankoti B-Tech 3rd year Amrapali Institute of technology and science,Haldwani 1

2. 2 3. ACKNOWLEDGEMENT An engineer with only theoretical knowledge is not a complete engineer. Practical knowledge is very important to develop and apply engineering skills. It gives me a great pleasure to have an opportunity to acknowledge and to express gratitude to those who were associated with me during my training at BHEL. I am very great-full to Mr. R.M. Meena for providing me with an opportunity to undergo training under his able guidance. Furthermore, special thanks to Mr. Pradeep Pandey for his help and support in haridwar. Last, but not the least, I would also like to acknowledge the immense pleasure, brought about by my friends Adhar,Ashis,Rohit as they pursued their training along with me. We shared some unforgettable moments together. I express my sincere thanks and gratitude to BHEL authorities for allowing me to undergo the training in this prestigious organization. I will always remain indebted to them for their constant interest and excellent guidance in my training work, moreover for providing me with an opportunity to work and gain experience. THANK YOU 3 4. B.H.E.L- An Overview BHEL or the Bharat Heavy Engineering Limited is one of the largest engineering and manufacturing organizations in the country and the BHEL, Haridwar is their gift to Uttaranchal. With two large manufacturing plants, BHEL in Haridwar is among the leading industrial organizations in the state. It has established a Heavy Electrical Equipment Plant or HEEP and a Central Foundry Forge Plant or CFFP in Haridwar. The Heavy Electrical Equipment Plant in Haridwar designs and manufactures turbo generators, AC and DC motors, gas turbines and huge steams. The Central Foundry Forge Plant in Haridwar deals with steel castings and manufacturing of steel forgings. The BHEL plants in Haridwar have earned the ISO - 9001 and 9002 certificates for its high quality and maintenance. These two units have also earned the ISO - 14001 certificates. Situate in Ranipur near Haridwar, the Bharat Heavy Engineering Limited employs over 8,000 people. BHEL is an integrated power plant equipment manufacturer and one of the largest engineering and manufacturing companies in India in terms of turnover. BHEL was established in 1964, ushering in the indigenous Heavy Electrical Equipment industry in India - a dream that has been more than realized with a well-recognized track record of performance. The company has been earning profits continuously since 1971-72 and paying dividends since 1976-77 .BHEL is engaged in the design, engineering, manufacture, construction, testing, commissioning and servicing of a wide range of products and services for the core sectors of the economy, viz. Power, Transmission, Industry, Transportation, Renewable Energy, Oil & Gas and Defence.BHEL has 15 manufacturing divisions, two repair units, four regional offices, eight service centres, eight overseas offices and 15 regional centres and currently operate at more than 150 project 4 5. sites across India and abroad. BHEL places strong emphasis on innovation and creative development of new technologies. Our research and development (R&D) efforts are aimed not only at improving the performance and efficiency of our existing products, but also at using state-of-the-art technologies and processes to develop new products. This enables us to have a strong customer orientation, to be sensitive to their needs and respond quickly to the changes in the market. The high level of quality & reliability of our products is due to adherence to international standards by acquiring and adapting some of the best technologies from leading companies in the world including General Electric Company,Alstom SA, Siemens AG and Mitsubishi Heavy Industries Ltd., together with technologies developed in our own R&D centres. Most of our manufacturing units and other entities have been accredited to Quality Management Systems (ISO 9001:2008), Environmental Management Systems (ISO 14001:2004) and Occupational Health & Safety Management Systems (OHSAS 18001:2007). BHEL has a share of around 59% in India's total installed generating capacity contributing 69% (approx.) to the total power generated from utility sets (excluding non-conventional capacity) as of March 31, 2012. We have been exporting our power and industry segment products and services for approximately 40 years. We have exported our products and services to more than 70 countries. We had cumulatively installed capacity of over 8,500 MW outside of India in 21 countries, including Malaysia, Iraq, the UAE, Egypt and New Zealand. Our physical exports range from turnkey projects to after sales services. BHEL work with a vision of becoming a world-class engineering enterprise, committed to enhancing stakeholder value. Our greatest strength is our highly skilled and committed workforce of over 49,000 employees. Every employee is given an equal 5 6. opportunity to develop himself and grow in his career. Continuous training and retraining, career planning, a positive work culture and participative style of management - all these have engendered development of a committed and motivated workforce setting new benchmarks in terms of productivity, quality and responsiveness. STEAM TURBINE A steam turbine is a mechanical device that extracts thermal energy from pressurized steam, and converts it into rotary motion. Its modern manifestation was invented by Sir Charles Parsons in 1884. It has almost completely replaced the reciprocating piston steam engine (invented by Thomas Newcomen and greatly improved by James Watt) primarily because of its greater thermal efficiency and higher power-to-weight ratio. Because the turbine generates rotary motion, it is particularly suited to be used to drive an electrical generator about 80% of all electricity generation in the world is by use of steam turbines. The steam turbine is a form of heat engine that derives much of its improvement in thermodynamic efficiency through the use of 6 7. multiple stages in the expansion of the steam, which results in a closer approach to the ideal reversible process. Types These arrangements include single casing, tandem compound and cross compound turbines. Single casing units are the most basic style where a single casing and shaft are coupled to a generator. Tandem compound are used where two or more casings are directly coupled together to drive a single generator. A cross compound Steam turbines are made in a variety of sizes ranging from small 1 hp (0.75 kW) units (rare) used as mechanical drives for pumps, compressors and other shaft driven equipment, to 2,000,000 hp (1,500,000 kW) turbines used to generate electricity. There are several classifications for modern steam turbines. Steam Supply and Exhaust Conditions These types include condensing, non-condensing, reheat, extraction and induction. Non-condensing or backpressure turbines are most widely used for process steam applications. The exhaust pressure is controlled by a regulating valve to suit the needs of the process steam pressure. These are commonly found at refineries, district heating units, pulp and paper plants, and desalination facilities where large amounts of low pressure process steam are available. Condensing turbines are most commonly found in electrical power plants. These turbines exhaust steam in a partially condensed state, typically of a quality near 90%, at a pressure well below atmospheric to a condenser. Reheat turbines are also used almost exclusively in electrical power plants. In a reheat turbine, steam flow exits from a high pressure section of the turbine and is returned to the boiler where additional superheat is added. The steam then goes back into an intermediate pressure section of the turbine and continues its expansion. 7 8. Casing or Shaft Arrangements Turbine arrangement features two or more shafts not in line driving two or more generators that often operate at different speeds. A cross compound turbine is typically used for many large applications. Principle of Operation and Design An ideal steam turbine is considered to be an isentropic process, or constant entropy process, in which the entropy of the steam entering the turbine is equal to the entropy of the steam leaving the turbine. No steam turbine is truly isentropic, however, with typical isentropic efficiencies ranging from 20%- 90% based on the application of the turbine. The interior of a turbine comprises several sets of blades, or buckets as they are more commonly referred to. One set of stationary blades is connected to the casing and one set of rotating blades is connected to the shaft. The sets intermesh with certain minimum clearances, with the size and configuration of sets varying to efficiently exploit the expansion of steam at each stage. Turbine Efficiency To maximize turbine efficiency, the steam is expanded, generating work, in a number of stages. These stages are characterized by how the energy is extracted from them and are known as impulse or reaction turbines. Most modern steam turbines are a combination of the reaction and impulse design. Typically, higher pressure sections are impulse type and lower pressure stages are reaction type. Impulse Turbines An impulse turbine has fixed nozzles that orient the steam flow into high speed jets. These jets contain significant kinetic energy, which the rotor blades, shaped like buckets, convert into shaft rotation as the steam jet changes direction. A pressure drop occurs across only the stationary blades, with a net increase in steam velocity across the stage. 8 9. Reaction Turbines In the reaction turbine, the rotor blades themselves are arranged to form convergent nozzles. This type of turbine makes use of the reaction force produced as the steam accelerates through the nozzles formed by the rotor. Steam is directed onto the rotor by the fixed vanes of the stator. It leaves the stator as a jet that fills the entire circumference of the rotor. The steam then changes direction and increases its speed relative to the speed of the blades. A pressure drop occurs across both the stator and the rotor, with steam accelerating through the stator and decelerating through the rotor, with no net change in steam velocity across the stage but with a decrease in both pressure and temperature, reflecting the work performed in the driving of the rotor. SPECIFICATIONS OF MACHINES AVAILABLE IN BLOCK-III: Vertical Boring Machine : Max diameter of work piece accommodated :10000mm to 12500mm Max height of work piece :5000mm Diameter of table :8750mm Max travel of vertical tool head RAM slides :3200mm Max travel of vertical tool heads from centre of Table :5250mm Max weight of work piece :200 T For N

• Published on
  13-Feb-2017

• View
  530

• Download
  28

Transcript

Bhel Haridwar Apprentice

• BHARAT HEAVY ELECTRICALS LIMITED

  Industrial Training

• General Awareness in steam Turbine Manufacturing.

  PRESENTATIONONPresentation By:-ADITYA SHARMA12ME126HCST, Farah, Mathura

• OVERVIEW OF BHELBHEL was established in 1964.BHEL is one of the only 7 Public Sector Undertakings (PSUs) of India clubbed under the esteemed 'Maharatna'status.On 1st February 2013, theGovernment of IndiagrantedMaharatnastatus toBHEL.BHEL has a share of 59% in Indias total installed power generating capacity.BHEL is engaged in the design, engineering, manufacture, construction, testing, commissioning and servicing of a wide range of products and services for the core sectors of the economy, viz. Power Transmission, Industry, Transportation (Railway), Renewable Energy, Oil & Gas and defence.BHEL has 15 manufacturing divisions, two repair units, four regional offices, eight service centers and 15 regional centers and currently operate at more than 150 project sites across India and abroad.

• MAIN MANUFACTURING UNITSBHEL Bhopal (Madhya Pradesh )BHEL Ramachandrapuram, Hyderabad (Andhra Pradesh)Transformer Plant, BHEL Jhansi(Uttar Pradesh)High Pressure Boiler Plant and Seamless Steel Tube Plant, Tiruchirapalli(Tamil Nadu) Boiler Auxiliaries Plant, Ranipet (Tamil Nadu)ElectronicsDivision and Electro Porcelain Division, Bangalore(KarnatakaJagdishpur (Uttar Pradesh)Rudrapur (Uttrakhand)Industrial ValvesPlant, Goindwal (Punjab)BHEL Ranipur, Haridwar (Uttarakhand) Bharat Heavy Plates and Vessels Limited(Vizag)

  Show you what I had found and maybe.

• BHEL HARIDWARIt is divided in 2 units i.e. Heavy Electrical Equipment Plant (HEEP) and Central Foundry Forge Plant (CFFP).I did my training at HEEP plant.HEEP plant is divided into 8 blocks.Steam turbines are manufactured at HEEP plant in block 3.

• BHEL HEEP PLANT, HARIDWAR

• HEAVY ELECTRICAL EQUIPMENT PLANT:BLOCK-1: Electrical Machine ShopBLOCK-2: Heavy Fabrication ShopBLOCK-3: Turbine Manufacturing ShopBLOCK-4: CIM (Coils & Insulation Manuf.)BLOCK-5: Condenser Fabrication & Forge ShopBLOCK-6: Fabrication Shop & Die ShopBLOCK-7: Carpentry & Heat Treatment ShopBLOCK-8: Heat Exchanger Shop

• BLOCK-3: TURBINE MANUFACTURING SHOP HMS (Heavy Machine Shop)Assembly SectionTurbine SectionBlade Section

• BLOCK 3 LAY-OUT

• STEAM TURBINES

  A turbine is a device that converts chemical energy into mechanical energy, specifically when a rotor of multiple blades or vanes is driven by the movement of a fluid or gas. In the case of a steam turbine, the pressure and flow of newly condensed steam rapidly turns the rotor. This movement is possible because the water to steam conversion results in a rapidly expanding gas. As the turbines rotor turns, the rotating shaft can work to accomplish numerous applications, often electricity generation.

• IMPULSE TURBINEREACTION TURBINE

  She was stabbed in the neck and her body dumped in the boot of former lover Bhayani's VW Golf. Prescription drugs safety net This inaugural event was held at one of the world’s most iconic dirt tracks, Eldora Speedway in Ohio. Il silmarillion epub ita download. We'll need to take up references Waugh, 50, who lived alone in a £600,000 flat in Marylebone, was brutally killed on or around 16 April 2012. The race, which was the first NASCAR-sanctioned national event held on a dirt track since 1970, brought American Ethanol to the forefront as Dillon finished in front in the No. 39 American Ethanol Chevrolet truck.

  IMPULSE TURBINE :The principle of the impulse steam turbine consists of a casing containing stationary steam nozzles and a rotor with moving or rotating buckets. The steam passes through the stationary nozzles and is directed at high velocity against rotor buckets causing the rotor to rotate at high speed.The following events take place in the nozzles :1. The steam pressure decreases.2. The enthalpy of the steam decreases.3. The steam velocity increases.4. The volume of the steam increases.TYPES OF STEAM TURBINES

• REACTION TURBINE :A reaction turbine has rows of fixed blades alternating with rows of moving blades. The steam expands first in the stationary or fixed blades where it gains some velocity as it drops in pressure. It then enters the moving blades where its direction of flow is changed thus producing an impulse force on the moving blades. In addition, however, the steam upon passing through the moving blades again expands and further drops in pressure giving a reaction force to the blades. This sequence is repeated as the steam passes through additional rows of fixed and moving blades.

• WORKING OF STEAM TURBINE:Impulse Turbine:-steam is expanded only in nozzles.Blade passage of constant cross-section area.Reaction Turbine:-Pressure drop in fixed & moving blade.Blade passage of varying cross-section area.

  LAGU ANAK ANAK HAPPY BIRTHDAY www stafaband co 1.mp3. Selamat Ulang Tahun - Jamrud (Rizky Febian feat Raden Irfan Cover).mp3. Free download lagu jamrud selamat ulang tahun stafa band. Download lagu SONGO (4.22 MB) dan Streaming lagu SONGO Video 3gp & mp4, Kumpulan lagu full album terbaru SONGO dapat di nikmati hanya di Stafaband. Jamrud Selamat Ulang Tahun Www Musik Lo Com Mama Trio Ambisi. Download FLV-Media Player latest version 2017 Download the free Applian FLV. Stafaband, sikwap Download Video Kamu Selamat Ulang Tahun Mp4 Mp3. Download lagu jamrud selamat ulang tahun stafa band. Category: D Happy Birthday Images Download Tags: Added: happybirthdayworld on. No information is available for this page.Learn why.

• TURBINES MANUFACTURED AT BHELThe various types of turbines are :-High pressure turbinesLow pressure turbinesIntermediate pressure turbines.

• H.P TURBINE BLADES

  Aturbine bladeis the individual component which makes up theturbine section of agas turbine. The blades are responsible for extracting energy from the high temperature, high pressure gas produced by the combustor.Size of its blades are smaller than IP & HP turbines.

  *

• LOW PRESSURE TURBINE BLADE Titanium alloys offer high strength to intermediate temperatures at a density almost half that of steel and nickel-based superalloys. As a result, they have been adopted widely in the fan and compressor stages of the gas turbine for both disc and blade applications.LP blade is larger than HP & IP.

• INTERMEDIATE PRESSURE TURBINEIntermediate pressure turbine having more pressure then L.P turbine and less than the high pressure turbine(H.P) . Its blade is larger than high pressure turbine.

• BLADE OF INTERMEDIATE PRESSURE TURBINEThe size of blades of I.P steam turbine is larger than H.P steam turbine , but smaller than L.P steam turbine.

• CASINGLower half

  Upper half

• GAS TURBINE:Gas turbine have been used for electricity generation.The gas turbine obtains its power by utilizing the energy of burnt gases & air which are at high Pressure and Temperature.

• For electricity generation, it is known as power turbine.For propulsion unit in aircraft, it is called aircraft turbine.

• CONCLUSION:-BHEL is the largest engineering and manufacturing enterprise in India .BHEL is a major contributor of equipment and systems to industries.At the all, till now BHEL is best in supply and manufacturing products.Summer Training gives the idea of general awareness in steam turbine manufacturing, & its process. Its provides practical idea to manufacturing several components of turbine.

• *
